| Apparaattype | Switch 24 poorten - Managed - stackable |
| Behuizingstype | Desktop, rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Poorten | 24x1/2.5/5/10GBase-T (UPOE) |
| Power Over Ethernet (PoE) | UPOE |
| PoE-budget | 580 W |
| Prestaties | Schakelcapaciteit: 640 Gbps
Stacking bandbreedte: 480 Gbps
Forwarding: 500 Mbps |
| Capaciteit | IPv4 routes: 24000
NetFlow-ingangen: 48000
VLAN ID's: 4000
Virtual Switch Interfaces (SVIs): 1000 |
| MAC-adrestabel grootte | 32000 entries |
| Jumbo Frame ondersteuning | 9198 bytes |
| Routing protocol | OSPF, BGP-4, RIP-1, RIP-2, EIGRP, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, EIGRP voor IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MLDv2, MLD, URPF, MSTP |
| Beheer op afstand protocol | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI, NTP |
| Encryptie-algoritme | 128-bit AES, 256-bit AES, DTLS |
| Authenticatiemethode | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Kenmerken | ARP-ondersteuning, Intrusion Detection System (IDS), IPv6-ondersteuning, DHCP snooping, Dynamic Trunking Protocol (DTP)-ondersteuning, Port Aggregation Protocol (PAgP)-ondersteuning, access control list (ACL)-ondersteuning, Quality of Service (QoS), virtual routing and forwarding-Lite (VRF-Lite), Dynamic ARP Inspection (DAI), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4-ondersteuning, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), remote Switched Port Analyzer (RSPAN), Management Information Base (MIB), draadloos Intrusion Prevention System (WIPS-BX), Class of Service (CoS), StackWise-480 technologie, StackPower technologie, Flexible NetFlow (FNF), 802.1x authenticatie, DiffServ Code Point (DSCP)-ondersteuning, radio resource management (RRM), IP source guard, Weighted Tail Drop (WTD), Bridge Protocol Data Unit (BPDU), Control Plane Protection (CoPP), spanning-tree root guard (STRG), RA guard, Energy-Efficient Ethernet (EEE), Embedded Event Manager (EEM), Protocol Independent Multicast (PIM), VLAN Trunking Protocol (VTP) v.3, MQC Audio Video Bridging (AVB), OBFL, Committed Information Rate (CIR), Media Access Control Security (MACsec) |
| Voldoet aan normen | IEEE 802.3, IEEE 802.3u, IEEE 802.11, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1as, IEEE 802.3at, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.1BA, IEEE 802.3bz |
| RAM | 4 GB |
| Flashgeheugen | 2 GB |
| Statusindicatoren | Status |
| Uitbreiding/connectiviteit |
| Interfaces | 24x1/2.5/5/10GBase-T RJ-45 UPOE - 60 W
1 x USB Type A
1 x beheer (mini-USB) Type B
1 x beheerconsole RJ-45
1 x beheer (Gigabit LAN) RJ-45
Networking stack device |
| Uitbreidingssleuven | 1 (totaal) / 1 (vrij) x uitbreidingssleuf |
| Voeding |
| Voedingsapparaat | Interne voeding |
| Geïnstalleerde hoeveelheid | 1 (geïnstalleerd) / 2 (max) |
| Stroomredundantie | Optioneel |
| Stroomredundantie | 1 + 1 (met optionele voeding) |
| Stroomverbruik | 1100 Watt |
| Vereiste spanning | AC 120/230 V (50/60 Hz) |
