Place of Origin:
Beijing
Brand Name:
WS-C3560X-24T-S
Model Number:
WS-C3560X-24T-S
| Attribute | Value |
|---|---|
| Private Mold | NO |
| Products Status | Stock |
| Ports | 24, 24 10/100/1000 Ports |
| Transmission Rate | 10/100/1000Mbps |
| Function | LACP, QoS, SNMP, stackable, VLAN Support |
| Communication Mode | Full-Duplex & Half-Duplex |
| Switch Capacity | 176G |
| Product Name | WS-C3560X-24T-S |
| Condition | NIB Original |
| Warranty | 1 Year |
| Device Type | Switch - 24 Ports - Managed |
| Lead time | 3~7 Days |
| Shipping | DHL UPS FEDEX |
Cisco Original 3560X series 24-Port Gigabit Ethernet Switch WS-C3560X-24T-S
The Cisco WS-C3560X-24T-S is a high-quality managed switch designed for enterprise and midsize
business networks. This Layer 3 switch is part of the popular Cisco Catalyst 3560X series, offering robust
performance with 24 x 10/100/1000 Ethernet Ports. It operates on the Data IP Base software, making it a
reliable choice for complex network architectures. Whether used for routing, switching, or data management,
the Cisco Catalyst 3560X-24T provides exceptional network efficiency.
| Specification | Details |
|---|---|
| Product | WS-C3560X-24T-S |
| Product Description | 3560X 24 Port Data IP Base |
| Device Type | Switch - 24 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 |
| Performance | Switching fabric bandwidth: 160 Gbps |
| Capacity | Virtual interfaces (VLANs): 1005 |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | RIP-1, RIP-2, HSRP, static IP routing, RIPng |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae |
| RAM | 256 MB |
| Flash Memory | 128 MB flash |
| Status Indicators | Port status, port transmission speed, port duplex mode, power, system, link/activity |
| Power Device | Internal power supply |
| Installed Qty | 1 (installed) / 2 (max) |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Features | Redundant Power System (RPS) connector |
| Dimensions | Width: 17.5 in, Depth: 18.1 in, Height: 1.8 in |
| Weight | 15.43 lbs |
