Catalyst 2960X series 24 Port gigabit Switch WS-C2960X-24TS-LL 2 x 1G SFP, LAN Lite

Catalyst 2960X series 24 Port gigabit Switch WS-C2960X-24TS-LL 2 x 1G SFP, LAN Lite

lan lite 2960 switch

lan lite network switch

Place of Origin:

Beijing

Brand Name:

Cisco

Model Number:

WS-C2960X-24TS-LL

Chat Now
Request A Quote
Product Details
Model:
WS-C2960X-24TS-LL
Device Type:
Switch - 24 Ports - Managed
Transmission Rate:
10/100/1000Mbps
Switch Capacity:
176Gbps
Private Mold:
NO
Condition:
NIB
Warranty:
1 Year
Highlight:

lan lite 2960 switch

,

lan lite network switch

Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
$215.00-257.00 per piece
Delivery Time
2-3 working days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
500 Piece/Pieces per Month
Related Products
Contact Us
Product Description
Catalyst 2960X series 24 Port gigabit Switch WS-C2960X-24TS-LL 2 x 1G SFP, LAN Lite
Product Attributes
Attribute Value
Model WS-C2960X-24TS-LL
Device Type Switch - 24 Ports - Managed
Transmission Rate 10/100/1000Mbps
Switch Capacity 176Gbps
Private Mold NO
Condition NIB
Warranty 1 Year
Product Description

Cisco Catalyst 2960-X Series Switches feature:

  • 24 or 48 Gigabit Ethernet ports with line-rate forwarding performance
  • 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP) uplinks or 2 fixed 10 Gigabit Ethernet SFP+ uplinks
  • PoE+ support with a power budget of up to 740W and Perpetual PoE
  • Cisco IOS LAN Base or LAN Lite1 and Cisco IOS IP Lite
  • Device management with web UI, over-the-air access via Bluetooth, Command-Line Interface (CLI), Simple Network Management Protocol (SNMP), and RJ-45 or USB console access
  • Network management with Cisco Prime®, Cisco Network Plug and Play, and DNA Center
  • Stacking with FlexStack-Plus and FlexStack-Extended
  • Layer 3 features with routed access (OSPF), static routing, and RIP
  • Visibility with DNS-AS and Full (Flexible) NetFlow
  • Security with 802.1X, SPAN and BPDU Guard
  • Reliability with higher MTBF and Enhanced Limited Lifetime Warranty (E-LLW)
  • Resiliency with optional dual field-replaceable power supplies
Technical Specifications
Product WS-C2960X-24TS-LL
Product Description Gigabit 2960-X 24 GigE. 2 x 1G SFP. LAN Lite
Interface Ethernet 10Base-T/100Base-TX/1000Base-T
Authentication Method Kerberos, RADIUS, Secure Shell (SSH), TACACS+
Data Transfer Rate 80 Gbps
Remote Management Protocol CLI, HTTP, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
Compliant Standards IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
MAC Address Table Size 16K entries
Max Units In A Stack 8
Power Over Ethernet (PoE) No
Form Factor Desktop, Rack-mountable
Jumbo Frame Support 9216 bytes
Nominal Voltage AC 120/230 V
Dimensions (W x D x H) 17.5 x 11 x 1.8 in
Weight 8.16 lbs
Expansion & Connectivity
Console ports USB (Type-B), Ethernet (RJ-45)
Stacking cable None
Power Redundancy Option (PWR-RPS2300)
Voltage range (Auto) 110V-240V
Power Consumption Operational 0.035KVA
Similar Models Comparison
Model Ports Uplink Ports Key Features
WS-C2960X-24TS-LL 24 x 10/100/1000 4 x SFP Advanced security features, VLAN support, LL (LAN Lite)
WS-C2960X-24TD-LL 24 x 10/100/1000 4 x SFP Enhanced PoE, LL (LAN Lite)
WS-C2960X-48TS-LL 48 x 10/100/1000 4 x SFP Higher port density, LL (LAN Lite)
WS-C2960X-48TD-LL 48 x 10/100/1000 4 x SFP Enhanced PoE, LL (LAN Lite)
WS-C3650-24TS-S 24 x 10/100/1000 4 x 1G Layer 3 routing capabilities, stackable
WS-C3850-24T-S 24 x 10/100/1000 4 x 1G/10G Advanced features, Layer 3, stackable
