Place of Origin:
Beijing, China
Brand Name:
Cisco
Model Number:
C9200L-48P-4G-A
| Attribute | Value |
|---|---|
| Product Name | C9200L-48P-4G-A |
| PoE Ports | 48 ports full POE+ |
| POE power | 740W |
| Transmission Rate | 10/100/1000Mbps |
| Uplink configuration | 4x 1G fixed uplinks |
| Switch Capacity | 176 Gbps |
| Private Mold | NO |
| Products Status | Stock |
| Package Weight | 14 kg |
C9200L-48P-4G-A is the Catalyst 9200L24 ports full PoE+ 4x10G uplink Switch, with Network Advantage software. Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.
| Model | C9200L-48P-4G-A |
| Downlinks total 10/100/1000 or PoE+ copper ports | 48 ports full POE+ |
| Uplink configuration | 4x 1G fixed uplinks |
| Default primary AC power supply | PWR-C5-1KWAC |
| Fans | Fixed redundant |
| Software | Network Advantage |
| Stacking bandwidth | 80 Gbps |
| DRAM | 2 GB |
| Flash | 4 GB |
| Chassis Dimensions | 1.73 x 17.5 x 11.3 in (4.4 x 44.5 x 28.8 cm) |
| Package Weight | 14 Kg |
| Switching capacity | 176 Gbps |
| Switch capacity with Stacking | 256 Gbps |
| Forwarding rate | 130.95 Mpps |
| Forwarding rate with Stacking | 190 Mpps |
| Chassis Dimensions | 1.73 x 17.5 x 11.3 Inches |
| Weight | 10.58 Pounds |
| Mean time between failures (hours) | 346,270 |
StackWise-80 and StackWise-160 Kit and cables
| Product number | Product description |
| C9200-STACK-KIT= | C9200 Stack Kit Spare |
| C9200L-STACK-KIT= | C9200L Stack Kit Spare |
| STACK-T4-50CM | 50CM Type 3 Stacking Cable |
| STACK-T4-1M | 1M Type 3 Stacking Cable |
| STACK-T4-3M | 3M Type 3 Stacking Cable |
| Product Number | Product Description |
| PWR-C5-600WAC/2= | 125WAC power supply spare |
| Product number | Product description |
|---|---|
| C9200L-48T-4G-A | Catalyst 9200L 48-port Data 4x1G uplink Switch, Network Advantage |
| C9200L-48T-4G-E | Catalyst 9200L 48-port Data 4x1G uplink Switch, Network Essentials |
| C9200L-48P-4G-A | Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Advantage |
| C9200L-48P-4G-E | Catalyst 9200L48-port PoE+ 4x1G uplink Switch, Network Essentials |
